TRIAC wall dimmer 0/1-10V Dimmable Power supply
Dimmer Power Supply 0/1-10V Triac Dimmable. IP20
Power range from 60W to 300W, High efficiency with sufficient power
2 hours 100% full-load burn-in test before shipping
OVP, OLP, OTP, and short circuit protection programmed
CE ROHS FCC certified
Additional information
| Power | 60W, 100W, 120W, 150W, 200W, 250W, 300W |
|---|---|
| Input | 100-240V, 175-240V |
| Output | 12V, 24V |
Product Processes
12V/24V 60W-300W Dimmable Power Supply
- VOLTAGE RANGE: AC100-240V/200-240V
- FREQUENCY RANGE:47-63Hz
- DC VOLTAGE: DC 12V/24V OUTPUT
- CURRENT RANGE: 60W 100W 150W 200W 250W 300W
- Dimming interface: Triac/0-10V
- Dimming range: 0~100%, LED start at 0.1% possible.
- Efficiency: >85%
- Working temperature: ta: -30 ~ 55 °C Tc: 80 °C
- Weight(G.W) :240g 290g
Product Details:
Selecting the Perfect Dimmable power supplies for Your lights
Product Feature
- 0/1-10v & Triac Dimming 2in1.
- Aluminum shell IP20 is non-waterproof, for indoor use or installed in a rainproof box.
- Ultra-thin fanless cooling design, no noise from the fan.
- 100% full load burn-in test.
- Protections: short circuit, overload, over-voltage, over-temp.
- Dimming interface: Triac/0-10v
- Apply to leading edge / trailing edge Triac dimmers and 0-10vdimming system.
- Built-in high-performance MCU dimming curve.
- Dimming range: 0~100%, LED start at 0.1% possible.
- Multi-current & wide voltage, suitable for different power LED.
- Short circuit / Over-heat / Overload protection.
- Compliant with Safety Extra Low Voltage standard.
Dimmable power supplies
| Series No. | Power (W) | AC input (V) | DC output (V*A) | Water Level | Size(mm) | Weight (KG) | Dimmable | PCS/CTN | CTN Size |
|---|---|---|---|---|---|---|---|---|---|
| CRS60-W1V12/24 | 60W | 100-240V | 12V/24V | IP20 | 230*50*30 | 0.35 | Triac & 0/1-10V 2in1 | 36 | 330*240*260 |
| CRS100-W1V12/24 | 100W | 100-240V | 12V/24V | IP20 | 230*50*30 | 0.35 | Triac & 0/1-10V 2in1 | 36 | 330*240*260 |
| CRS150-W1V12/24 | 150W | 175-240V | 12V/24V | IP20 | 287*50*30 | 0.5 | Triac & 0/1-10V 2in1 | 55 | 400*315*270 |
| CRS200-H1V12/24 | 200W | 175-240V | 12V/24V | IP20 | 287*50*30 | 0.5 | Triac & 0/1-10V 2in1 | 55 | 400*315*270 |
| CRS250-H1V12/24 | 250W | 175-240V | 12V/24V | IP20 | 287*50*30 | 0.5 | Triac & 0/1-10V 2in1 | 55 | 400*315*270 |
| CRS300-H1V12/24 | 300W | 175-240V | 12V/24V | IP20 | 287*50*30 | 0.5 | Triac & 0/1-10V 2in1 | 55 | 400*315*270 |
